鼻筛窦钳 Nasal sieve sinus pliers
|
|
||||||||
|
|
B-012-XG |
-D |
|
B-013-XG |
-D |
|
B-014-XG |
-D |
|
-Z |
-Z |
-Z |
||||||
|
-X |
-X |
-X |
||||||
|
-JX |
-JX |
-JX |
||||||
● 渐扁形钳头更方便狭窄区域的操作
● Flattened nippers are more convenient to operate in narrow areas.
● 碗口后斜结构使得夹取组织更牢稳
● The oblique structure behind the bowl mouth makes the clamping tissue more stable.
● 尖、圆钝、头形，满足精准手术又避免戳伤
● Point, round, blunt, head-shaped, to meet the precision of surgery and avoid stabbing
● 高强度材料实现杆部更纤细、视野更开阔
● High-strength material to achieve finer rod and wider field of vision
● 钳杆后端预留间隙增加推进范围实现更大的夹持力；
● Back-end reserved clearance enlarges propulsion range to achieve greater clamping force
● PVD镀膜使耐腐蚀性、耐磨损性得到了极大改善；
● The corrosion resistance and wear resistance of PVD coating have been greatly improved.
产品参数 Product parameters
|
鼻筛窦钳【鼻窦抓钳】Nasal sieve sinus pliers |
|||||||||||
|
型号 |
规格 |
头部 head |
总长 |
||||||||
|
L |
W |
H（前） |
H（后） |
||||||||
|
KRT-B-012 |
-XG |
-D |
卵圆形 |
0° |
13.5mm |
4.6mm |
2.4mm |
4.2mm |
134mm |
||
|
-Z |
12.5mm |
3.8mm |
2.3mm |
4.1mm |
133mm |
||||||
|
-X |
8.5mm |
3.1mm |
2.1mm |
3.7mm |
130mm |
||||||
|
-JX |
7mm |
2.6mm |
1.8mm |
3.3mm |
129mm |
||||||
|
KRT-B-013 |
-XG |
-D |
卵圆形 |
45° |
13.5mm |
4.6mm |
2.4mm |
4.2mm |
130mm |
||
|
-Z |
12.5mm |
3.8mm |
2.3mm |
4.1mm |
129mm |
||||||
|
-X |
8.5mm |
3.1mm |
2.1mm |
3.7mm |
127mm |
||||||
|
-JX |
7mm |
2.6mm |
1.8mm |
3.3mm |
|||||||
|
KRT-B-014 |
-XG |
-D |
卵圆形 |
90° |
13.5mm |
4.6mm |
2.4mm |
4.2mm |
123mm |
||
|
-Z |
12.5mm |
3.8mm |
2.3mm |
4.1mm |
|||||||
|
-X |
8.5mm |
3.1mm |
2.1mm |
3.7mm |
|||||||
|
-JX |
7mm |
2.6mm |
1.8mm |
3.3mm |
|||||||
